P1CP-SAF-R501G50W-20
20 dB Couplers from P1dB
RF coaxial 20 dB Directional Coupler, frequency from 500 MHz to 1000 MHz. Power up to 50 Watts, with SMA female connectors. Limited to stock on hand.
| Specifications |
|
Part Number:
P1CP-SAF-R501G50W-20
|
|
Status:
Standard
|
|
Datasheet:
|
|
RoHS Compliance:
 Yes
|
|
Coupler Type:
Directional
|
|
Coupling (dB):
20.0
|
|
Frequency Min (MHz):
500.0
|
|
Frequency Max (MHz):
1000.0
|
|
Power Handling (W):
50.0
|
|
Insertion Loss (dB):
0.2
|
|
Isolation (dB):
25.0
|
|
Amplitude Imbalance (dB):
0.75
|
|
Connectors:
SMA
|
|
Directivity (dB):
25.0
|
|
Typ. Input VSWR:
1.1:1
|
|
Typ. Output VSWR:
1.1:1
|
