    P1AT-29MF-40G2W-10

    P1AT-29MF-40G2W-10

    RF Attenuator, 2.92mm Male to 2.92mm Female, 10 dB, 2 W.
    Frequency DC to 40 GHz with a 1.25 max VSWR.

    $ 219.00 $ 219.00

    • Connector 1
    • Connector 2
    • Max VSWR
    • Frequency Max (GHz)
    • Attenuation, Min (dB)
    • Attenuation (dB)
    • Attenuation Step Size (dB)
    • Avg. Power (W)
    • Accuracy (dB)
    Add to cart
    Terms and Conditions
    30-day money-back guarantee
    Shipping: 2-3 Business Days
    Contact Us
    Connector 1: 2.92mm Male
    Connector 2: 2.92mm Female
    Max VSWR: 1.4:1
    Frequency Max (GHz): 40.0
    Attenuation, Min (dB): 10.0
    Attenuation (dB): 10.0
    Attenuation Step Size (dB): Fixed
    Avg. Power (W): 2.0
    Accuracy (dB): 0.6
