P1CP-SAF-1218G10W-10
10 dB Couplers from P1dB
RF coaxial 10 dB Directional Coupler, frequency range 12 GHz to 18 GHz. Power up to 10 Watts with SMA female connectors.
| Specifications |
|
Part Number:
P1CP-SAF-1218G10W-10
|
|
Status:
Standard
|
|
Datasheet:
|
|
RoHS Compliance:
 Yes
|
|
Coupler Type:
Directional
|
|
Coupling (dB):
10.0
|
|
Frequency Min (MHz):
12400.0
|
|
Frequency Max (MHz):
18000.0
|
|
Power Handling (W):
10.0
|
|
Insertion Loss (dB):
0.5
|
|
Isolation (dB):
15.0
|
|
Amplitude Imbalance (dB):
0.5
|
|
Connectors:
SMA
|
|
Directivity (dB):
15.0
|
|
Typ. Input VSWR:
1.3:1
|
|
Typ. Output VSWR:
1.3:1
|
