P1CP-SAF-R502G50W-20

20 dB Couplers from P1dB

RF coaxial 20 dB Directional Coupler frequency from 500 MHz to 2000 MHz. Power up to 50 Watts, with SMA female connectors. Limited to stock on hand.

Specifications
Part Number:
P1CP-SAF-R502G50W-20
Status:
Standard
Datasheet:
RoHS Compliance:
Yes
Coupler Type:
Directional
Coupling (dB):
20.0
Frequency Min (MHz):
500.0
Frequency Max (MHz):
2000.0
Power Handling (W):
50.0
Insertion Loss (dB):
0.4
Isolation (dB):
23.0
Amplitude Imbalance (dB):
0.75
Connectors:
SMA
Directivity (dB):
23.0
Typ. Input VSWR:
1.2:1
Typ. Output VSWR:
1.2:1
Qty: in Unit(s)

218.00 218.00 218.0 USD

218.00

Pricelist
Min. Qty
Price
  • 1
    $ 218.0
In Stock:1.0
