Low cost hand formable cables

     P1dB has a large inventory of RF coaxial cable assemblies that can be formed by hand. This section lists P1dB's hand formable assemblies priced under $20.

            Evaluation samples are available for many of P1dB's low cost formable cables.      Contact:   sales@p1db.com

     Also called conformable cable assemblies, P1dB offers 50 Ohm cables in either .085 or .141 diameter, with or without a PVC jacket. Connector choices include the most popular SMA male straight, SMA female, SMA female bulkhead and SMA male right angle. These easy to bend assemblies require no special tooling and will retain their shape once the desired bend is made. Hand formed coaxial cables offer similar performance to semi-rigid assemblies to 27 GHz, depending on the connectors. Bending the cable multiple times will not degrade the electrical performance. Constructed with a tinned-copper braid outer shield, P1dB's conformable cables provide excellent RF shielding.

     If you are looking for SMA formable cables and the maximum frequency of your project is 10 GHz, consider P1dB's selection of $8.95 cables: P1CA-SAMSAMLF-085CC-xx (where -xx- is the length, from 3 up to 12 inch). Offered exclusively online from P1dB.

     Many more formable cables can be found in P1dB's "Hand Formable Cables" section. If you can't locate the length or connector options you need, contact us at sales@p1dB.com.

BUILD THEN BUY A NEW RF CABLE HERE

Click Here if you do not find the desiredLow cost hand formable cables.

Sale
P1CA-SAMSAF-085CC-6
Cable Assembly, SMA Male to SMA Female, 085CC Conformable Coax, 6 inch, frequency to 26.5 GHz.
14.95 14.95 USD
Pricelist
Min. Qty
Price
  • 1
    $ 14.95
  • 10
    $ 14.45
Connector 1
SMA Male
Connector 2
SMA Female
Cable Type
085CC
Cable_Feature
Conformable
Length (in)
6.0
Max. Frequency (GHz)
26.5
Outer Diameter (in)
0.085
Sale
P1CA-SAMSAF-085CC-12
Cable Assembly, SMA Male to SMA Female, 085CC Conformable Coax, 12 inch, frequency to 26.5 GHz.
14.95 14.95 USD
Pricelist
Min. Qty
Price
  • 1
    $ 14.95
  • 10
    $ 14.45
Connector 1
SMA Male
Connector 2
SMA Female
Cable Type
085CC
Cable_Feature
Conformable
Length (in)
12.0
Max. Frequency (GHz)
26.5
Outer Diameter (in)
0.085
Sale
P1-SMAP/SMAP-141CC-17
SMA Male to SMA Male cable assembly using 141CC Conformable Coax, 17 inch, frequency to 26.5 GHz.
16.95 16.95 USD
Pricelist
Min. Qty
Price
  • 1
    $ 16.95
  • 10
    $ 16.45
ConnContact2
Gold Plated Brass
Data.F1
1.0
VSWR1
1.25
Connector 1
SMA Male
Connector 2
SMA Male
Cable Type
141CC
Cable_Feature
Conformable
Length (in)
17.0
Max. Frequency (GHz)
26.5
Outer Diameter (in)
0.141
Sale
P1CA-SAMSAMLF-085CC-12
SMA Male to SMA Male cable assembly, 085CC Conformable (no jacket) Coax, 12 inch.
Frequency to 10 GHz.
Available exclusively from P1dB.
8.95 8.95 USD
Pricelist
Min. Qty
Price
  • 5
    $ 8.95
Connector 1
SMA Male
Connector 2
SMA Male
Cable Type
085CC
Cable_Feature
Conformable
Length (in)
12.0
Outer Diameter (in)
0.085
