Connector 1:
SMA Male
|
|
Connector 2:
SMA Male Right Angle
|
|
Cable Type:
RG-58
|
|
Cable_Feature:
RG Type Flex
|
|
Length (in):
15.0
|
|
Outer Diameter (in):
0.195
|
|
Max. Frequency (GHz):
6.0
|
|
Data.F1:
0.1
|
|
Data.F2:
0.4
|
|
Data.F3:
1.0
|
|
Data.F4:
5.0
|
|
VSWR1:
1.2
|
|
VSWR2:
1.25
|
|
VSWR3:
1.3
|
|
VSWR4:
1.35
|
|
IL1:
0.05
|
|
IL2:
0.1
|
|
IL3:
0.18
|
|
IL4:
0.6
|
|
VoP:
65.9
|
|
ConnNut1:
Gold Plated Brass
|
|
ConnBody1:
Gold Plated Brass
|
|
ConnContact1:
Gold Plated Brass
|
|
ConnNut2:
Tin-Zinc-Copper-Alloy Plated Brass
|
|
ConnBody2:
Tin-Zinc-Copper-Alloy Plated Brass
|
|
ConnContact2:
Gold Plated Brass
|
|
InnerCond:
TPC 19/.0072
|
|
Dielectric Material:
PE
|
|
JacketMat:
PVC
|
|
MinBend:
1.0
|
|
OpTmpMin:
-40.0
|
|
OpTmpMax:
80.0
|
|
Shield1:
TPC Briad
|
