Phase Matched Cables

For applications requiring very high frequency, P1dB has cable and connector options to phase match up to 67 GHz. Using 2.92mm connectors for frequencies up to 40 GHz, 2.4mm connectors to 50 GHz or 1.85mm connectors to 67 GHz, P1dB has high performance low loss flexible cable solutions.

For a phase matched cable assembly quote, contact P1dB : sales@ p1db.com. Describe the cable set that must be phase matched: # of cables, connector type, maximum frequency and match frequency, phase match desired (i.e. 5 ps or 5 degrees, etc ).

Click Here if you do not find the desiredPhase Matched Cables.

P1CA-29M29M-SS085-60-PM-SET4 A set of 4 phase matched cable assemblies, 2.92mm male to 2.92mm male connectors operating to 40 GHz. Length 60 inch. Phase matched +/- 5 degrees at 18 GHz. Supplied as a phase matched set (4 cables), test data included.. Price is per set. Contact P1dB if you require a larger quantity of cables as a phase matched set. ~~$ 493.77~~ $ 493.77 493.77000000000004 USD Pricelist Min. Qty Price 1 $ 493.77	P1CA-24F24M-130F-24-PM-1PS Phase matched cable assemblies, 2.4mm female to 2.4mm male, 130F flexible coax, 24 inch. Phase matched +/- 1 ps. Frequency DC to 50 GHz. Supplied as skew (delay) matched pairs (min buy quantity 2 pcs). Price is per cable. Contact P1dB for larger matched sets of cables (>2). Each set includes S-Parameter data. ~~$ 286.68~~ $ 286.68 286.68 USD Pricelist Min. Qty Price 2 $ 286.68	P1CA-SAMSAMRA-SS141-6.5 Flex RF cable assembly, SMA Male to SMA Male Right Angle, SS141, 6.5 inch. Frequency DC - 10 GHz. ~~$ 19.94~~ $ 19.94 19.94 USD Pricelist Min. Qty Price 15 $ 19.94	P1CA-29M29M-SS085-12-PM-SET16 Phase matched cable assemblies, 2.92mm male to 2.92mm male connectors. Length 12 inch. Phase matched within +/- 5 degrees DC to 20 GHz. Supplied as a set of 16 matched cables. Price is per cable. Test data supplied with each cable. ~~$ 119.85~~ $ 119.85 119.85000000000001 USD Pricelist Min. Qty Price 16 $ 119.85
P1CA-29M29M-SS085-60-PM-SET10 A set of 10 phase matched cable assemblies, 2.92mm male to 2.92mm male connectors operating to 40 GHz. Length 60 inch. Phase matched +/- 5 degrees at 1.575 MHz. Supplied as a phase matched set (10 cables), test data included.. Price is per set. ~~$ 1,345.87~~ $ 1,345.87 1345.8700000000001 USD	P1CA-29M29M-SS085-24-PM-SET10 A set of 10 phase matched cable assemblies, 2.92mm male to 2.92mm male connectors operating to 40 GHz. Length 24 inch. Phase matched +/- 5 degrees at 1.575 MHz. Supplied as a phase matched set (10 cables), test data included.. Price is per set. ~~$ 1,264.92~~ $ 1,264.92 1264.92 USD	P1CA-29M29M-SS085-12-PM-SET15 A set of 15 phase matched cable assemblies, 2.92mm male to 2.92mm male connectors operating to 40 GHz. Length 12 inch. Phase matched +/- 5 degrees at 1.575 MHz. Supplied as a phase matched set (15 cables), test data included.. Price is per set. ~~$ 1,858.96~~ $ 1,858.96 1858.96 USD
