P1CP-SAF-R518G50W-LL-30
30 dB Directional Low Loss Coupler Operating from 0.5 to 18 GHz.
Power handling up to 50 Watts with SMA Connectors.
Limited to stock on hand.
$ 795.00 $ 795.00 795.0 USD
Pricelist
Min. Qty
Price
  • 1
    $ 795.0
Coupler Type
Directional
Coupling (dB)
30.0
Frequency Min (MHz)
500.0
Frequency Max (MHz)
18000.0
Power Handling (W)
50.0
Insertion Loss (dB)
0.3
Isolation (dB)
20.0
Amplitude Imbalance (dB)
1.0
Connectors
SMA
Directivity (dB)
15.0
P1CP-SAF-R502G50W-30
RF coaxial 30 dB Directional Coupler frequency from 500 MHz to 2000 MHz.
Power up to 50 Watts, with SMA female connectors.
Limited to stock on hand.
$ 218.00 $ 218.00 218.0 USD
Pricelist
Min. Qty
Price
  • 1
    $ 218.0
Coupler Type
Directional
Coupling (dB)
30.0
Frequency Min (MHz)
500.0
Frequency Max (MHz)
2000.0
Power Handling (W)
50.0
Insertion Loss (dB)
0.4
Isolation (dB)
23.0
Amplitude Imbalance (dB)
0.75
Connectors
SMA
Directivity (dB)
23.0
P1CP-SAF-R501G50W-30
RF coaxial 30 dB Directional Coupler frequency from 500 MHz to 1000 MHz.
Power up to 50 Watts, with SMA female connectors.
Limited to stock on hand.
$ 205.00 $ 205.00 205.0 USD
Pricelist
Min. Qty
Price
  • 1
    $ 205.0
Coupler Type
Directional
Coupling (dB)
30.0
Frequency Min (MHz)
500.0
Frequency Max (MHz)
1000.0
Power Handling (W)
50.0
Insertion Loss (dB)
0.2
Isolation (dB)
25.0
Amplitude Imbalance (dB)
0.75
Connectors
SMA
Directivity (dB)
25.0
P1CP-SAF-1218G50W-20
RF coaxial 20 dB Directional Coupler, frequency range 12 GHz to 18 GHz.
Power up to 20 Watts with SMA female connectors.
Limited to stock on hand.
$ 265.00 $ 265.00 265.0 USD
Coupler Type
Directional
Coupling (dB)
20.0
Frequency Min (MHz)
12400.0
Frequency Max (MHz)
18000.0
Power Handling (W)
50.0
Insertion Loss (dB)
0.5
Isolation (dB)
15.0
Amplitude Imbalance (dB)
0.5
Connectors
SMA
Directivity (dB)
15.0
P1CP-SAF-0716G50W-20
Coaxial RF 20 dB Directional Coupler, frequency band 7.5 to 16 GHz.
Power up to 50 Watts with SMA female connectors.
Limited to stock on hand.
$ 265.00 $ 265.00 265.0 USD
Coupler Type
Directional
Coupling (dB)
20.0
Frequency Min (MHz)
7500.0
Frequency Max (MHz)
16000.0
Power Handling (W)
50.0
Insertion Loss (dB)
0.5
Isolation (dB)
15.0
Amplitude Imbalance (dB)
0.75
Connectors
SMA
Directivity (dB)
17.0
P1CP-SAF-0712G50W-20
Coaxial RF 20 dB Directional Coupler, frequency band 7 to 12 GHz.
Power up to 50 Watts with SMA female connectors.
Limited to stock on hand.
$ 265.00 $ 265.00 265.0 USD
Coupler Type
Directional
Coupling (dB)
20.0
Frequency Min (MHz)
7000.0
Frequency Max (MHz)
12400.0
Power Handling (W)
50.0
Insertion Loss (dB)
0.3
Isolation (dB)
17.0
Amplitude Imbalance (dB)
0.5
Connectors
SMA
Directivity (dB)
17.0
P1CP-SAF-0408G50W-20
Coaxial RF 20 dB Directional Coupler, frequency band 4 to 8 GHz.
Power up to 50 Watts with SMA female connectors.
Limited to stock on hand.
$ 255.00 $ 255.00 255.0 USD
Coupler Type
Directional
Coupling (dB)
20.0
Frequency Min (MHz)
4000.0
Frequency Max (MHz)
8000.0
Power Handling (W)
50.0
Insertion Loss (dB)
0.25
Isolation (dB)
20.0
Amplitude Imbalance (dB)
0.75
Connectors
SMA
Directivity (dB)
20.0
P1CP-SAF-0218G50W-20
20 dB Directional Coupler Operating from 2 to 18 GHz.
Power handling 50 Watts, SMA female.
Limited to stock on hand.
$ 595.00 $ 595.00 595.0 USD
Pricelist
Min. Qty
Price
  • 1
    $ 595.0
Coupler Type
Directional
Coupling (dB)
20.0
Frequency Min (MHz)
2000.0
Frequency Max (MHz)
18000.0
Power Handling (W)
50.0
Insertion Loss (dB)
0.9
Isolation (dB)
12.0
Amplitude Imbalance (dB)
0.5
Connectors
SMA
Directivity (dB)
15.0
P1CP-SAF-0208G50W-20
20 dB Directional Coupler Operating from 2 to 8 GHz up to 50 Watts with SMA Connectors.
Limited to stock on hand.
$ 205.00 $ 205.00 205.0 USD
Pricelist
Min. Qty
Price
  • 1
    $ 205.0
Coupler Type
Directional
Coupling (dB)
20.0
Frequency Min (MHz)
2000.0
Frequency Max (MHz)
8000.0
Power Handling (W)
50.0
Insertion Loss (dB)
0.45
Isolation (dB)
20.0
Amplitude Imbalance (dB)
0.5
Connectors
SMA
Directivity (dB)
20.0
P1CP-SAF-0204G50W-20
20 dB Directional Coupler Operating from 2 to 4 GHz up to 50 Watts with SMA Connectors.
Limited to stock on hand.
$ 205.00 $ 205.00 205.0 USD
Pricelist
Min. Qty
Price
  • 1
    $ 205.0
Coupler Type
Directional
Coupling (dB)
20.0
Frequency Min (MHz)
2000.0
Frequency Max (MHz)
4000.0
Power Handling (W)
50.0
Insertion Loss (dB)
0.2
Isolation (dB)
22.0
Amplitude Imbalance (dB)
0.75
Connectors
SMA
Directivity (dB)
22.0
P1CP-SAF-0104G50W-20
RF coaxial 20 dB Directional Coupler, frequency range 1 GHz to 4 GHz.
Power up to 50 Watts with SMA female connectors.
Limited to stock on hand.
$ 205.00 $ 205.00 205.0 USD
Pricelist
Min. Qty
Price
  • 1
    $ 205.0
Coupler Type
Directional
Coupling (dB)
20.0
Frequency Min (MHz)
1000.0
Frequency Max (MHz)
4000.0
Power Handling (W)
50.0
Insertion Loss (dB)
0.4
Isolation (dB)
23.0
Amplitude Imbalance (dB)
0.5
Connectors
SMA
Directivity (dB)
22.0
P1CP-SAF-0102G50W-20
RF coaxial 20 dB Directional Coupler, frequency 1 to 2 GHz.
Power up to 50 Watts with SMA female connectors.
Limited to stock on hand.
$ 205.00 $ 205.00 205.0 USD
Pricelist
Min. Qty
Price
  • 1
    $ 205.0
Coupler Type
Directional
Coupling (dB)
20.0
Frequency Min (MHz)
1000.0
Frequency Max (MHz)
2000.0
Power Handling (W)
50.0
Insertion Loss (dB)
0.2
Isolation (dB)
25.0
Amplitude Imbalance (dB)
0.75
Connectors
SMA
Directivity (dB)
25.0
P1CP-SAF-R518G50W-LL-20
20 dB Directional Low Loss Coupler Operating from 0.5 to 18 GHz up to 50 Watts with SMA Connectors.
Limited to stock on hand.
$ 795.00 $ 795.00 795.0 USD
Pricelist
Min. Qty
Price
  • 1
    $ 795.0
Coupler Type
Directional
Coupling (dB)
20.0
Frequency Min (MHz)
500.0
Frequency Max (MHz)
18000.0
Power Handling (W)
50.0
Insertion Loss (dB)
0.3
Isolation (dB)
20.0
Amplitude Imbalance (dB)
1.0
Connectors
SMA
Directivity (dB)
15.0
P1CP-SAF-R502G50W-20
RF coaxial 20 dB Directional Coupler frequency from 500 MHz to 2000 MHz.
Power up to 50 Watts, with SMA female connectors.
Limited to stock on hand.
$ 218.00 $ 218.00 218.0 USD
Pricelist
Min. Qty
Price
  • 1
    $ 218.0
Coupler Type
Directional
Coupling (dB)
20.0
Frequency Min (MHz)
500.0
Frequency Max (MHz)
2000.0
Power Handling (W)
50.0
Insertion Loss (dB)
0.4
Isolation (dB)
23.0
Amplitude Imbalance (dB)
0.75
Connectors
SMA
Directivity (dB)
23.0
P1CP-SAF-R501G50W-20
RF coaxial 20 dB Directional Coupler, frequency from 500 MHz to 1000 MHz.
Power up to 50 Watts, with SMA female connectors.
Limited to stock on hand.
$ 205.00 $ 205.00 205.0 USD
Pricelist
Min. Qty
Price
  • 1
    $ 205.0
Coupler Type
Directional
Coupling (dB)
20.0
Frequency Min (MHz)
500.0
Frequency Max (MHz)
1000.0
Power Handling (W)
50.0
Insertion Loss (dB)
0.2
Isolation (dB)
25.0
Amplitude Imbalance (dB)
0.75
Connectors
SMA
Directivity (dB)
25.0
P1CP-SAF-1218G10W-10
RF coaxial 10 dB Directional Coupler, frequency range 12 GHz to 18 GHz.
Power up to 10 Watts with SMA female connectors.
$ 265.00 $ 265.00 265.0 USD
Coupler Type
Directional
Coupling (dB)
10.0
Frequency Min (MHz)
12400.0
Frequency Max (MHz)
18000.0
Power Handling (W)
10.0
Insertion Loss (dB)
0.5
Isolation (dB)
15.0
Amplitude Imbalance (dB)
0.5
Connectors
SMA
Directivity (dB)
15.0
P1CP-SAF-0716G10W-10
Coaxial RF 10 dB Directional Coupler, frequency band 7.5 to 16 GHz.
Power up to 10 Watts with SMA female connectors.
Limited to stock on hand.
$ 265.00 $ 265.00 265.0 USD
Coupler Type
Directional
Coupling (dB)
10.0
Frequency Min (MHz)
7500.0
Frequency Max (MHz)
16000.0
Power Handling (W)
10.0
Insertion Loss (dB)
1.0
Isolation (dB)
12.0
Amplitude Imbalance (dB)
0.75
Connectors
SMA
Directivity (dB)
12.0
P1CP-SAF-0408G10W-10
Coaxial RF 10 dB Directional Coupler, frequency band 4 to 8 GHz.
Power up to 10 Watts with SMA female connectors.
Limited to stock on hand.
$ 255.00 $ 255.00 255.0 USD
Coupler Type
Directional
Coupling (dB)
10.0
Frequency Min (MHz)
4000.0
Frequency Max (MHz)
8000.0
Power Handling (W)
10.0
Insertion Loss (dB)
0.25
Isolation (dB)
20.0
Amplitude Imbalance (dB)
0.75
Connectors
SMA
Directivity (dB)
20.0
P1CP-SAF-0218G10W-10
10 dB Directional Coupler Operating from 2 to 18 GHz up to 10 Watts with SMA Connectors.
Limited to stock on hand.
$ 495.00 $ 495.00 495.0 USD
Pricelist
Min. Qty
Price
  • 1
    $ 495.0
Coupler Type
Directional
Coupling (dB)
10.0
Frequency Min (MHz)
2000.0
Frequency Max (MHz)
18000.0
Power Handling (W)
10.0
Insertion Loss (dB)
1.3
Isolation (dB)
12.0
Amplitude Imbalance (dB)
0.5
Connectors
SMA
Directivity (dB)
15.0
P1CP-SAF-0208G10W-10
10 dB Directional Coupler Operating from 2 to 8 GHz up to 10 Watts with SMA Connectors.
Limited to stock on hand.
$ 205.00 $ 205.00 205.0 USD
Pricelist
Min. Qty
Price
  • 1
    $ 205.0
Coupler Type
Directional
Coupling (dB)
10.0
Frequency Min (MHz)
2000.0
Frequency Max (MHz)
8000.0
Power Handling (W)
10.0
Insertion Loss (dB)
1.0
Isolation (dB)
20.0
Amplitude Imbalance (dB)
0.5
Connectors
SMA
Directivity (dB)
20.0
