P1AT-29MF-40G2W-10
RF Attenuator, 2.92mm Male to 2.92mm Female, 10 dB, 2 W.
Frequency DC to 40 GHz with a 1.25 max VSWR.
$ 219.00 $ 219.00 219.0 USD
Max VSWR
1.4:1
Frequency Max (GHz)
40.0
Attenuation (dB)
10.0
Avg. Power (W)
2.0
Accuracy (dB)
0.6
P1AT-29MF-40G1W-6
RF Attenuator, 2.92mm Male to 2.92mm Female, 6 dB, 1 W.
Frequency DC to 40 GHz with a max VSWR 1.4.
Limited to stock on hand.
$ 167.75 $ 167.75 167.75 USD
Pricelist
Min. Qty
Price
  • 1
    $ 167.75
Max VSWR
1.4:1
Frequency Max (GHz)
40.0
Attenuation (dB)
6.0
Avg. Power (W)
1.0
Accuracy (dB)
0.5
P1AT-29MF-40G1W-30
RF Attenuator, 2.92mm Male to 2.92mm Female, 30 dB, 1 W.
Frequency DC to 40 GHz with a max VSWR 1.4.
Limited to stock on hand.
$ 167.75 $ 167.75 167.75 USD
Pricelist
Min. Qty
Price
  • 1
    $ 167.75
Max VSWR
1.4:1
Frequency Max (GHz)
40.0
Attenuation (dB)
30.0
Avg. Power (W)
1.0
Accuracy (dB)
0.8
P1AT-29MF-40G1W-3
RF Attenuator, 2.92mm Male to 2.92mm Female, 3 dB, 1 W.
Frequency DC to 40 GHz with a max VSWR 1.4.
Limited to stock on hand, replacement part P1AT-29MF-40G2W-3.
$ 167.75 $ 167.75 167.75 USD
Pricelist
Min. Qty
Price
  • 1
    $ 167.75
Max VSWR
1.4:1
Frequency Max (GHz)
40.0
Attenuation (dB)
3.0
Avg. Power (W)
1.0
Accuracy (dB)
0.5
P1AT-29MF-40G1W-20
RF Attenuator, 2.92mm Male to 2.92mm Female, 20 dB, 1 Watt.
Frequency DC to 40 GHz with a max VSWR 1.4.
Limited to stock on hand, replacement part P1AT-29MF-40G2W-20.
$ 167.75 $ 167.75 167.75 USD
Pricelist
Min. Qty
Price
  • 1
    $ 167.75
Max VSWR
1.4:1
Frequency Max (GHz)
40.0
Attenuation (dB)
20.0
Avg. Power (W)
1.0
Accuracy (dB)
0.6
P1AT-29MF-40G1W-10
RF Attenuator, 2.92mm Male to 2.92mm Female, 10 dB, 1 W.
Frequency DC to 40 GHz with a max VSWR 1.4.
Limited to stock on hand, replacement part P1AT-29MF-40G2W-10.
$ 167.75 $ 167.75 167.75 USD
Pricelist
Min. Qty
Price
  • 1
    $ 167.75
Max VSWR
1.4:1
Frequency Max (GHz)
40.0
Attenuation (dB)
10.0
Avg. Power (W)
1.0
Accuracy (dB)
0.6
P1AT-24MF-50G1W-30
RF Attenuator, 2.4mm Male to 2.4mm Female, 50 GHz, 30 dB, 1 Watt.
Limited to stock on hand.
$ 277.95 $ 277.95 277.95 USD
Pricelist
Min. Qty
Price
  • 1
    $ 277.95
Connector 1
2.4mm Male
Connector 2
2.4mm Female
Max VSWR
1.35:1
Frequency Max (GHz)
50.0
Attenuation, Min (dB)
30.0
Attenuation (dB)
30.0
Attenuation Step Size (dB)
Fixed
Avg. Power (W)
1.0
Accuracy (dB)
0.75
P1AT-24MF-50G1W-20
RF Attenuator, 2.4mm Male to 2.4mm Female, 50 GHz, 20 dB, 1 Watt.
Limited to stock on hand.
$ 277.95 $ 277.95 277.95 USD
Pricelist
Min. Qty
Price
  • 1
    $ 277.95
Connector 1
2.4mm Male
Connector 2
2.4mm Female
Max VSWR
1.35:1
Frequency Max (GHz)
50.0
Attenuation, Min (dB)
20.0
Attenuation (dB)
20.0
Attenuation Step Size (dB)
Fixed
Avg. Power (W)
1.0
Accuracy (dB)
0.75
P1AT-24MF-50G2W-6
RF Attenuator, 2.4mm Male to 2.4mm Female, 50 GHz, 6 dB, 2 Watt.
VSWR 1.30 max DC to 50 GHz.
$ 277.95 $ 277.95 277.95 USD
Pricelist
Min. Qty
Price
  • 1
    $ 277.95
Connector 1
2.4mm Male
Connector 2
2.4mm Female
Max VSWR
1.30
Frequency Max (GHz)
50.0
Attenuation (dB)
6.0
Avg. Power (W)
2.0
P1AT-24MF-50G1W-03
RF Attenuator, 2.4mm Male to 2.4mm Female, 50 GHz, 3 dB, 1 Watt.
Limited to stock on hand.
$ 277.95 $ 277.95 277.95 USD
Pricelist
Min. Qty
Price
  • 1
    $ 277.95
Connector 1
2.4mm Male
Connector 2
2.4mm Female
Max VSWR
1.35:1
Frequency Max (GHz)
50.0
Attenuation, Min (dB)
3.0
Attenuation (dB)
3.0
Attenuation Step Size (dB)
Fixed
Avg. Power (W)
1.0
P1AT-18MF-65G1W-6
RF Attenuator, 1.85mm Male to 1.85mm Female, 65 GHz, 6 dB, 1 Watt.
Limited to stock on hand.
Replacement part is P1AT-18MF-67G2W-6.
$ 409.74 $ 409.74 409.74 USD
Pricelist
Min. Qty
Price
  • 1
    $ 409.74
Max VSWR
1.35:1
Frequency Max (GHz)
65.0
Attenuation (dB)
6.0
Avg. Power (W)
1.0
Accuracy (dB)
0.75
P1AT-18MF-65G1W-30
RF Attenuator, 1.85mm Male to 1.85mm Female, 65 GHz, 30 dB, 1 Watt.
Limited to stock on hand.
Replacement part is P1AT-18MF-67G2W-30.
$ 409.74 $ 409.74 409.74 USD
Pricelist
Min. Qty
Price
  • 1
    $ 409.74
Max VSWR
1.35:1
Frequency Max (GHz)
65.0
Attenuation (dB)
30.0
Avg. Power (W)
1.0
Accuracy (dB)
1.25
P1AT-18MF-65G1W-20
RF Attenuator, 1.85mm Male to 1.85mm Female, 65 GHz, 20 dB, 1 Watt.
Limited to stock on hand.
Replacement part is P1AT-18MF-67G2W-20.
$ 409.74 $ 409.74 409.74 USD
Pricelist
Min. Qty
Price
  • 1
    $ 409.74
Max VSWR
1.35:1
Frequency Max (GHz)
65.0
Attenuation (dB)
20.0
Avg. Power (W)
1.0
Accuracy (dB)
1.0
P1CP-SAF-0716G50W-30
Coaxial RF 30 dB Directional Coupler, frequency band 7.5 to 16 GHz.
Power up to 50 Watts with SMA female connectors.
Limited to stock on hand.
$ 265.00 $ 265.00 265.0 USD
Coupler Type
Directional
Coupling (dB)
30.0
Frequency Min (MHz)
7500.0
Frequency Max (MHz)
16000.0
Power Handling (W)
50.0
Insertion Loss (dB)
0.5
Isolation (dB)
15.0
Amplitude Imbalance (dB)
0.75
Connectors
SMA
Directivity (dB)
17.0
P1CP-SAF-0408G50W-30
Coaxial RF 30 dB Directional Coupler, frequency band 4 to 8 GHz.
Power up to 50 Watts with SMA female connectors.
Limited to stock on hand.
$ 255.00 $ 255.00 255.0 USD
Coupler Type
Directional
Coupling (dB)
30.0
Frequency Min (MHz)
4000.0
Frequency Max (MHz)
8000.0
Power Handling (W)
50.0
Insertion Loss (dB)
0.25
Isolation (dB)
20.0
Amplitude Imbalance (dB)
0.75
Connectors
SMA
Directivity (dB)
20.0
P1CP-SAF-0218G50W-30
30 dB Directional Coupler Operating from 2 to 18 GHz up to 50 Watts with SMA Connectors.
Limited to stock on hand.
$ 595.00 $ 595.00 595.0 USD
Coupler Type
Directional
Coupling (dB)
30.0
Frequency Min (MHz)
2000.0
Frequency Max (MHz)
18000.0
Power Handling (W)
50.0
Insertion Loss (dB)
0.9
Isolation (dB)
10.0
Amplitude Imbalance (dB)
0.5
Connectors
SMA
Directivity (dB)
12.0
P1CP-SAF-0208G50W-30
30 dB Directional Coupler Operating from 2 to 8 GHz up to 50 Watts with SMA Connectors.
Limited to stock on hand.
$ 205.00 $ 205.00 205.0 USD
Pricelist
Min. Qty
Price
  • 1
    $ 205.0
Coupler Type
Directional
Coupling (dB)
30.0
Frequency Min (MHz)
2000.0
Frequency Max (MHz)
8000.0
Power Handling (W)
50.0
Insertion Loss (dB)
0.45
Isolation (dB)
20.0
Amplitude Imbalance (dB)
0.5
Connectors
SMA
Directivity (dB)
18.0
P1CP-SAF-0204G50W-30
30 dB Directional Coupler Operating from 2 to 4 GHz up to 50 Watts with SMA Connectors.
Limited to stock on hand.
$ 205.00 $ 205.00 205.0 USD
Pricelist
Min. Qty
Price
  • 1
    $ 205.0
Coupler Type
Directional
Coupling (dB)
30.0
Frequency Min (MHz)
2000.0
Frequency Max (MHz)
4000.0
Power Handling (W)
50.0
Insertion Loss (dB)
0.2
Isolation (dB)
22.0
Amplitude Imbalance (dB)
0.75
Connectors
SMA
Directivity (dB)
22.0
P1CP-SAF-0104G50W-30
RF coaxial 30 dB Directional Coupler, frequency range 1 GHz to 4 GHz.
Power up to 30 Watts with SMA female connectors.
Limited to stock on hand.
$ 205.00 $ 205.00 205.0 USD
Pricelist
Min. Qty
Price
  • 1
    $ 205.0
Coupler Type
Directional
Coupling (dB)
30.0
Frequency Min (MHz)
1000.0
Frequency Max (MHz)
4000.0
Power Handling (W)
50.0
Insertion Loss (dB)
0.4
Isolation (dB)
21.0
Amplitude Imbalance (dB)
0.5
Connectors
SMA
Directivity (dB)
20.0
P1CP-SAF-0102G50W-30
RF coaxial 30 dB Directional Coupler, frequency 1 to 2 GHz.
Power up to 50 Watts with SMA female connectors.
Limited to stock on hand.
$ 205.00 $ 205.00 205.0 USD
Pricelist
Min. Qty
Price
  • 1
    $ 205.0
Coupler Type
Directional
Coupling (dB)
30.0
Frequency Min (MHz)
1000.0
Frequency Max (MHz)
2000.0
Power Handling (W)
50.0
Insertion Loss (dB)
0.2
Isolation (dB)
25.0
Amplitude Imbalance (dB)
0.75
Connectors
SMA
Directivity (dB)
25.0
