SMP and SMPM

P1dB stocks popular lengths of SMP straight and SMP right angle assemblies, as well as SMP Miniature (SMPM or SSMP) straight or SMPM right angle flexible assemblies.

Choose from our high performance, triple shield low loss SS085 cable or for best value look at P1dB's 085 conformable assemblies.

For very tight spaces, consider  P1dB's "Tight-Flex" cable series with SMP, SMPM and SMA connector options. Tight-Flex assemblies feature a minimum bend radius of 0.25 inch, low loss triple shield construction with an outer jacket of 0.104 inch diameter. Typical Insertion Loss at 10GHz is 0.8 dB per foot.

Tight-Flex assemblies use part number "P1CA-STM (for SMA connector) , P1CA-TPF (for SMP connector) or P1CA-TMF (for SMPM/ SSMP connector)".

P1dB offers SMA male to SMP, SMA female to SMP  and SMP to SMP flex assemblies. We can quote any length, typical cycle time for new builds is 30 days.

           Evaluation samples are available for many of P1dB's SMP and SMPM cables. Contact sales@p1db.com.




Click Here if you do not find the desiredSMP and SMPM.

Sale
P1CA-SAMRASPFRA-SS085-48
SMA Male Right Angle to SMP Female Right Angle RF flex cable using SS085 high performance coax, 48 inch, operating to 18 GHz.
68.22 USD
ConnContact2
Gold Plated Beryllium Copper
Data.F1
1.0
VSWR1
1.2
Connector 1
SMA Male Right Angle
Connector 2
SMP Female Right Angle
Cable Type
SS085
Cable_Feature
High Performance
Length (in)
48.0
Max. Frequency (GHz)
18.0
Outer Diameter (in)
0.104
Sale
P1CA-SAMSPF-085CJ-5
Cable Assembly, SMA Male to SMP Female, 085CJ Jacketed Conformable Coax, 5 inches
24.95 24.95 USD
Pricelist
Min. Qty
Price
  • 1
    $ 24.95
  • 10
    $ 23.95
Connector 1
SMA Male
Connector 2
SMP Female
Cable Type
085CJ
Cable_Feature
Conformable, Jacketed
Length (in)
5.0
Max. Frequency (GHz)
18.0
Outer Diameter (in)
0.103
Sale
P1CA-SAMSPF-085CC-5
Cable Assembly, SMA Male to SMP Female, 085CC Conformable Coax (no jacket) , 5 inches
24.95 24.95 USD
Pricelist
Min. Qty
Price
  • 1
    $ 24.95
  • 10
    $ 23.95
Connector 1
SMA Male
Connector 2
SMP Female
Cable Type
085CC
Cable_Feature
Conformable
Length (in)
5.0
Max. Frequency (GHz)
18.0
Sale
P1CA-SAMSPF-085CJ-10
Cable Assembly, SMA Male to SMP Female, 085CJ Jacketed Conformable Coax, 10 inches
24.95 24.95 USD
Pricelist
Min. Qty
Price
  • 1
    $ 24.95
  • 10
    $ 23.95
Connector 1
SMA Male
Connector 2
SMP Female
Cable Type
085CJ
Cable_Feature
Conformable, Jacketed
Length (in)
10.0
Max. Frequency (GHz)
18.0
Outer Diameter (in)
0.103
Sale
P1CA-SAMSPF-085CJ-8
Cable Assembly, SMA Male to SMP Female, 085CJ Jacketed Conformable Coax, 8 inches
24.95 24.95 USD
Pricelist
Min. Qty
Price
  • 1
    $ 24.95
  • 10
    $ 23.95
Connector 1
SMA Male
Connector 2
SMP Female
Cable Type
085CJ
Cable_Feature
Conformable, Jacketed
Length (in)
8.0
Max. Frequency (GHz)
18.0
Outer Diameter (in)
0.103
